- Place of Origin: XI'AN
- Brand Name: Xi an aerospace pumps Company limited
- Model Number: Hydraulic turbine
Application fields:
1 ) Hydrocracking in petroleum refining : act as auxiliary feed oil pumps between the high-pressure separator and mortgage separator for.
2 ) Fertilizer Ammonia industry: between the high pressure absorber and mortgage separators, such as gas absorption and pressure fluid of CO high pressure energy is recycle in analytical systems.
3 ) pressure energy -rich liquid of absorb bottom outlet in desulfuration systems, need reduce pressure to flash dissolved hydrocarbons before being transported to the regeneration tower, rich liquid pressure energy was recycle by hydraulic turbine;
4 ) Coal Chemical : platinum reforming unit using fluid pressure differential from extraction column to stripper ( diethylene glycol ethers , aromatic hydrocarbons, water ) setting hydraulic turbine.
5 ) urban water supply : power generation does not have the conventional conditions, the pump act as turbine to drive power generator when the water has certain conditions
6 ) transport crude oil or refined oil from high pressure pipeline to tank farm ;
Features:
Multistage hydraulic turbine, API610 BB5 structure, horizontal, double casing, radial split structure ; multi-stage closed impeller ; same middle and each vane shape , with the number of stages of change , and more forms bearing structure ; compact, power recovery turbine increases with the number of stages increases , ease of series production, recycling a wide range of high recovery power on various occasions have adopted this structure.
- Place of Origin: XI'AN
- Brand Name: Xi an aerospace pumps Company limited
- Model Number: Hydraulic turbine
During order following parameter need be provided:
Correlation technique requirements such as pump type or relevant parameter, main parts material, inlet pressure, shaft sealing form, bearing structure, rotation direction of pump and motor.
